DELL EMC D-NWG-FN-23 Practice Exams
Last updated on Oct 22,2026- Exam Code: D-NWG-FN-23
- Exam Name: Dell Networking Foundations 2023
- Certification Provider: DELL EMC
- Latest update: Oct 22,2026
A network administrator has a Dell EMC switch that has been configured with several VLANs. Each VLAN switch virtual interface (SVI) has an IP address assigned to it with each of them on different subnets. In addition, routing has been enabled on the switch.
Which action occurs when the switch receives a packet on one of its SVIs but the destination IP address of the packet does not match the IP address of that SVI?
- A . Switch checks its routing table and forwards the packet accordingly.
- B . Switch duplicates the packet and sends it to all interfaces.
- C . Switch replies back to the source with an ICMP Reject packet.
- D . Switch drops the packet.
Which of the following is an optional LLDP TLV?
- A . Chassis ID
- B . System Name
- C . Port ID
- D . Time-to-live
Which switch should Spanning Tree Protocol choose to become the root bridge in the election process?
- A . 22-33-44-55-66-78 : 32768
- B . 11-22-33-44-55-66 : 36864
- C . 22-33-44-55-66-77 : 36864
- D . 11-22-33-44-55-65 : 32768
What is the dotted decimal notation for a /29 prefix?
- A . 255.255.255.192
- B . 255.255.255.252
- C . 255.255.255.240
- D . 255.255.255.248
A technician has one stack of three N3024. The technician removes the master unit without powering off the stack. This unit is reconfigured with new IP address in the same Layer 2 network.
Which management issue is the result?
- A . A duplicate MAC address
- B . A duplicate IP address
- C . Lost switch configuration
- D . A switch that flashes red LED
Refer to the output shown:
Which two statements describe the state of configuration of interfaces gi1/0/1-24? (Choose two.)
- A . The interfaces are administratively Down.
- B . Spanning tree is NOT blocking any interfaces.
- C . The interfaces have negotiated to mode trunk.
- D . The interfaces are in access mode VLAN 1.
- E . The interfaces are administratively Up.
Which Dell EMC Networking M-Series 10 GbE switch model supports a VLT?
- A . MXL
- B . M6220
- C . M6348
- D . M8024-K
Which command shows active telnet sessions on Dell N-Series switches?
- A . Show hosts
- B . Show sessions
- C . Show users accounts
- D . Show line telnet
What action needs to be performed to enable SSH on a new switch?
- A . Enable web services
- B . Create a key pair using the crypto commands
- C . Update the switch to the latest firmware
- D . Disable telnet access
Which subnet mask provides only two valid IP addresses that can be assigned to hosts?
- A . 255.255.255.248
- B . 255.255.255.254
- C . 255.255.255.252
- D . 255.255.255.256
